Description
The GRX40 is an RX series solid body electric guitar model introduced by Ibanez for 2000. It is part of the entry-level GIO line. Features a solid body mated to a maple neck with a 22-fret rosewood fingerboard with dot inlays. Components include Ibanez pickups in and HSS configuration and a six-screw synchronized tremolo bridge.
-
SPECS
- neck type
- GRXMaple neck
- top/back/body
- Poplar body
- fretboard
- Jatoba fretboardWhite dot inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- T106 bridge
- string space
- 10.5mm
- neck pickup
- Infinity RS (S) neck pickupPassive/Ceramic
- middle pickup
- Infinity RS (S) middle pickupPassive/Ceramic
- bridge pickup
- Infinity R (H) bridge pickupPassive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- string gauge
- .009/.011/.016/.024/.032/.042
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5″
- a : Width
- 42mm at NUT
- b : Width
- 57mm at 22F
- c : Thickness
- 19.5mm at 1F
- d : Thickness
- 21.5mm at 12F
- Radius :
- 305mmR
-
-
-
SWITCHING SYSTEM
-
CONTROLS
