Description
AIR192x4
The perfect choice for solo performers who want studio-quality recordings!
With the AIR 192|4, you can create flawless 24-bit/192kHz studio-quality recordings with an intuitive and easy-to-use audio interface. The AIR 192|4 enables you to record up to 2 channels at once with its dedicated XLR+¼” balanced combo input, and an all-new ¼” instrument input that has a specially-designed gain and impedance stage to provide the most accurate representation of a guitar or bass plugged directly into the interface.
We’ve included software to match your style!
The AIR 192|4 comes complete with a software package that has everything to get you started. With 2 powerful DAWs to suit your production needs, AIR 192|4 includes Pro Tools | First M-Audio Edition, and Ableton Live Lite.
We’ve also added an entire Effects Plugin, Virtual Instruments and Loop package to cater to all your production needs. Whether you need a guitar tone, reverb, or delay we’ve got your effects needs covered with Eleven Lite, 20 effect plugins and AIR’s Creative FX Collection. With the included AIR Virtual Instrument plugins, you’ll have a virtual drum machine, synth, strings, percussion, organ and piano plugins to add world-class-sounding instruments to your songs with ease.
Crystal Preamps, Pristine A/D Converters and Premium Components
Our engineers designed the Crystal Preamps to provide you with a transparent, low-noise preamp that guarantees the best sound from your microphones and captures your performance exactly the way you intended. The AIR 192|4 incorporates pristine A/D converters for 24-bit resolution digital audio with explosive dynamic range that captures every nuance and subtlety of the performance.
Hear the performance now-not a second later
When recording, you want to focus on capturing that perfect moment, and getting the best performance out of your artist and talent. You don’t want to be bogged down by “clicks,” “pops” or latency. The AIR 192|4 not only features a high-speed USB connection for providing the lowest round trip latency (2.59ms*) between your machine and your hardware, but it also features monitor mix control for listening directly to the source inputs, providing you with zero-latency technology.
SPECIFICATIONS
Mic Input 1 (balanced XLR)
- FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.1 dB)
- DYNAMIC RANGE: 104 dB (A-weighted)
- SIGNAL-TO-NOISE RATIO: 104 dB (+1.0 dBu, A-weighted)
- THD+N: 0.003%
- PREAMP EIN: -128 dBu (max gain, 150 Ω: source, A-weighted)
- MAX INPUT LEVEL: +1.5 dBu
- GAIN RANGE: 55 dB
Line Input 1 (balanced 1/4″ [6.35 mm] TRS)
- FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.05 dB)
- SIGNAL-TO-NOISE RATIO: 101 dB (1 kHz, +4 dBu, A-weighted)
- THD+N: 0.003%
- MAX INPUT LEVEL: 16 dBu
- GAIN RANGE: 55 dB
Inst Input 2 (unbalanced 1/4″ [6.35 mm] TS)
- FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.05 dB)
- DYNAMIC RANGE: 100 dB (A-weighted)
- SIGNAL-TO-NOISE RATIO: 102 dB (+ 4 dBu, A-weighted)
- THD+N: 0.004%
- MAX INPUT LEVEL: 6 dBu
- INPUT IMPEDANCE: 1 MΩ
- GAIN RANGE: 24 dB
Main Outputs, L and R (balanced, differential 1/4″ [6.35 mm] TRS)
- FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.06 dB)
- DYNAMIC RANGE / SIGNAL-TO-NOISE RATIO: 102 dB (A-weighted)
- THD+N: 0.005%
- MAX OUTPUT LEVEL: +7 dBu (1 kHz, -1 dBFS)
Headphone Output (impedance-balanced 1/4″ [6.35 mm] TRS)
- THD+N: 0.005%
- OUTPUT IMPEDANCE: 10 Ω
General
- POWER: USB-bus-powered
- DIMENSIONS (WIDTH X DEPTH X HEIGHT): 8.0″ x 6.0″ x 2.76″ (20.42 cm x 15.24 cm x 7.0 cm)
- WEIGHT: 2.0 lbs. 0.9 kg
