Description
Record. Rehearse. Rest. Repeat.
When you need an expressive drum kit for recording and rehearsal duties, the TD-27KV2 V-Drums delivers. With generously sized pads all round, there’s plenty of space to get comfortable behind the kit. Then there’s the natural and superior expression that you only get from Roland’s unique digital snare, hi-hat, and ride pads. And it’s all hooked up to the updated TD-27 module, complete with new preset kits, effects, and processing capabilities—based on the same technology found in Roland’s flagship TD-50X. Practice with songs via wireless Bluetooth® audio. Record up to 28 channels of audio through a single USB cable, and then take your sound out on the road with assignable direct audio outputs. Whether practicing, recording, rehearsing, or gigging, a drummer’s life is a busy one—so pick the kit that can do it all.
- Kit configuration
- Drum sound module: TD-27 x 1
Snare: PD-140DS x 1
Tom: PDX-100 x 3
Hi-hat: VH-14D x 1
Crash1: CY-12C-T x 1
Crash2: CY-14C-T x 1
Ride: CY-18DR x 1
Kick: KD-10 x 1
Drum stand: MDS-STD2 x 1 *1 - Extra trigger input jack
- 4 (AUX1-AUX3, CRASH 2) *2
- SIZE AND WEIGHT
- Dimensions
- 1,550(W) x 1,200 (D) x 1,200 (H) mm
61-1/16 (W) x 47-1/4 (D) x 47-1/4 (H) inches
(including Kick pad, Cymbals, Hi-hat stand and Drum throne) - Weight
- 33 kg / 72 lbs 13 oz
- OTHER
- Accessories
- Sound module mount
AC adaptor
Special connection cable
Connection cable (Crash2)
Drum key
Setup Guide
Owner’s manuals - Options (sold separately)
- Cymbal mount: MDY series
Pad mount: MDH series
Personal drum monitor: PM series
V-Drums accessory package: DAP series
V-Drums mat: TDM series
Noise eater: NE-10, NE-1 - * This package does not include a kick pedal, a snare stand, a hi-hat stand, a drum throne, and a SD card.*1 Drums stand might be different from MDS-STD2 in some countries because of country factors.
*2 CRASH 2 jack is used for CY-14C-T of 2nd crash cymbal.
14-Inch Digital Snare
The PD-140DS digital snare pad works with the high-speed processing in the TD-27 module to bring the ultimate expression to your snare work. A three-layer mesh head is fitted to a standard 14-inch shell for natural rebound and feel. The multi-element sensor system tracks your playing across the pad, with head, rimshots, and cross-stick techniques all instantly detected in real time—without needing to change settings in the module.
14-Inch Digital Hi-Hat
With unrivaled touch sensitivity, tonal variation, and open/closed resolution, the VH-14D is simply the best electronic hi-hat available. The 14-inch top/bottom cymbal design mounts on a standard acoustic hi-hat for an authentic look and feel. Playing dynamics, stick techniques, and foot articulations are all captured with perfect detail, thanks to the high-resolution detection system and lightning-fast module processing.
18-Inch Digital Ride Cymbal
The CY-18DR brings limitless tonal colors to your ride playing. From edge to bell, every articulation is detected with ultra-detailed dynamics and response. Techniques from cymbal rolls to soft bell strokes are fully translated, and you can even mute the bow and bell with a gentle finger touch.
Thin Crash Cymbals
The TD-27KV2 comes with thin-profile V-Cymbals from the V-Drums Acoustic Design series, offering more natural movement when played. And just like acoustic cymbals, you can grab the edge to choke the sound and draw out different tones depending on whether you play the bow or the edge.
Authentic Kick Feel—Without the Noise
A nice solid kick drum usually comes with a nice loud noise. Sometimes that’s exactly what you want, but your family or neighbors may not feel the same way. The KD-10 kick pad absorbs much of the noise thanks to its rubber cover combined with a dedicated cushion—but retains that satisfying kick drum “thud” when a beater buries into a bass drum head. And it’s compatible with all standard kick pedals, both single and double.
Feel the Sound of Prismatic
Roland’s Prismatic Sound Modeling brings you an electronic drumming experience like no other. We start with carefully curated samples of real drums and percussion, recorded by top players in leading studios. Next, we bring these static samples to life with advanced modeling that recreates the acoustic behavior between each sample for a smooth, true-to-life drumming experience.
A Warehouse Full of Drum Sounds at Your Disposal
The updated and enhanced TD-27 module features 75 preset kits developed with top professional drummers. Explore 10 all-new kits, plus newly enhanced versions of the three most popular kits from the original version of the TD-27 module. An additional collection of new samples is also available for layering and combining with the preset kits or adding to your own custom setups.
Download More Drum Sounds from Roland Cloud
If you want to audition even more kits and percussion sounds, the TD-27 module now supports Roland Cloud content. Expand your options with an ever-growing selection of sounds, samples, and custom kits from top V-Drums artists. Just create your free Roland Cloud account, check out what’s new, and expand your repertoire today.
Seek Your Signature Drum Sound
With acoustic drums, you personalize the sound by swapping heads, adjusting the tuning, applying damping, changing out kick beaters, and more. You can do the same with the TD-27 module and its hands-on controls and intuitive editing tools. The module’s layering features have also been enhanced, making it easier to create fat, hybrid sounds. Edits are saved automatically as you go, so you can always stay focused on playing.
Import Samples to Perfect Your Performance
Some performances need specific sounds. With the TD-27 module, you can import and trigger original single-shot drum hits or introduce audio loops, sequences, and more. Going further, imported samples can be mixed and layered with internal sounds to build any kit you can imagine.
Wirelessly Stream Songs and Backing Tracks
Push your drumming further by playing along with your favorite bands—including your own. Wirelessly stream songs and backing tracks through the TD-27 module from your smartphone via Bluetooth audio. You can even record your performances—with or without backing—to hear where you need to tighten things up.
Multi-Channel Drum Recording—Using a Single Cable
In the studio, the TD-27 module’s USB audio interface makes computer music production simple, with up to 28 audio channels available through a single cable. MIDI is also supported via USB and dedicated I/O ports, allowing you to sync with other MIDI devices and trigger sounds in computer-based software.
Share Your Music Easily with Onboard Recording
With the TD-27 module, you can easily record your drumming at any time—with or without a backing track—without needing a computer or external recorder. It’s a great way to stay in the flow and get your ideas down quickly. You can also listen back and evaluate your playing to decide if you need to put in some more work before the gig. Or maybe export your drum recording to an SD card and share it with bandmates to incorporate your drumming into the next demo.
Split Your Sound Across Multiple Outputs
The TD-27 module features stereo outputs for the overall drum sound, plus two additional direct outputs for independent mixing. So, it’s no problem when you arrive at the gig or studio and the sound engineer wants the kick drum on channel one, snare on channel two, and everything else as a stereo pair. And with the stereo aux input, you can connect a monitor feed and listen along with the kit sound—including a click track—via headphones.
Gain of Thrones
On some gigs, you may not have someone to help balance the front-of-house sound. So, as you take your seat on the drum throne, you’re in complete control of the sound that drives the rest of the band. With the TD-27 module’s intuitive user interface, you can quickly adjust the overall volume, individual drum levels, and effects directly from your playing position. Everyone is happy—especially the audience.
Expand Your Kit (and Your Potential)
With the TD-27KV2, you’re not stuck with a static setup. When you’re ready to expand your kit, the module’s three auxiliary trigger inputs make it easy to add additional Roland pads—giving you even more creative firepower.
Your Personal Onboard Drum Coach
Coach mode supports your daily practice sessions, complete with progress tracking that makes learning effective and rewarding. Play through warm-ups, develop your sense of groove, tempo, and timing, and even work on your stamina—all with a score that highlights your progress and motivates you to improve.
Fast-Track Your Progress with Melodics for V-Drums
Melodics™ for V-Drums—a free application for macOS and Windows—features a curated set of drum lessons to develop your sense of rhythm, timing, and muscle memory. Subscribers can access additional premium content that includes over 70 lessons, with more added each week.
